Ford transit custom camper van kitchen furniture unit (standard premium)
From
£1,795.00
Here at Coolwhip Campers we pride ourselves in the bespoke options which we can offer. See below our beautiful colour range, visualise yourself with our state of the art software by clicking the button ‘Van Visualiser’.
If you already know what you want then select your options below.
For the best possible experience we recommend you use the ‘Van Visualiser’ tool on a desktop computer, tablet or laptop.
To view our range of bespoke and standard colours please click the link below.
The Ford Transit Custom premium kit has been designed and pre-scribed to fit perfectly flush, straight into your camper van, minimising work and saving a huge amount of time. With our clever integrated floor system, you can build your units with ease, simply click pieces into the rebated floor base, prewire and install any appliances, then simply push the units back and fit. The beauty of our concept has changed the small van conversion concept all together, allowing you to remove the units if necessary. This kit will also fit the Twin sliding door variant, however will need some minor scribing adjustments when fitting.
- High pressure laminated birch
- Solid oak work top and folding table
- Real oak tambour door
- Integrated floor system for simple installation
- Grill/ sink flush oak worktop style
- Soft close drawer
- Soft close door hinges
- Overhead LED top locker
- Full size window surround splashback
- Full LED shelving system throughout
- Kickboards for Rock ‘N’ Roll Bed
- Table with folding leg & rail
- Table storage system
- LED cubby hole
- Worktop storage flap
- Grill/sink cut outs with flush design
- Personalised coasters
- Easy to follow picture instructions
SWB
Overall length: 2241mm | Height 1322mm
LWB
Overall length 2511mm | Height 1322mm
Work top
Height: 760mm
Fridge Aperture
Width: 390mm | Height 536mm
Aperture will accommodate most popular campervan 12v fridges, however the fridge door can’t protrude past the fridge width, we recommend the Revace 50l
Rock & Roll bed
Suitable for beds 112cm or smaller
Van floor
Must have an overall thickness no greater than 16mm from the ribs (see shop)
Ply-Lining
Must have our Two-piece ply-ling on O/S with full height rear quarter panel (see shop)
Induction hob and sink
Sterling Power 2800W Flush Fitting Double Induction Hob and CAN LA1400 Rectangular Sink 320 x 260 (The hob is recessed perfectly flush with the oak worktop and the sink is undermounted)
- SWB includes 2 x doors in top locker
- LWB includes 3 x doors in top locker
- We constantly strive to improve our products, therefore pictures may differ slightly from current design
- This kit contains a separate splash back, control panel box (needs scribing) and a hanging top locker
